PWM Solar Charge Controller
Distributor
| Model | ATO-LS-60 |
| System Voltage | DC 12V/24V, DC 24V/48V,automatically switch |
| The Max Voltage of The Solar Panel Input | 50V (12V/24V), 100V (24V/48V) |
| Self Los | -13mA |
| Max Charge Current | 20A |
| Max Discharge Current | 20A |
| LVD | (9-11V), 21V (18-22V), 42V (36-44V) |
| LVR | 12.6V (11-13.5V), 25.2V (22-27V), 50.4V (44-54V) |
| Floating Voltage | 13.8V (13-15V), 27.6V(26-30V), 55.2V(52-60V) |
| Increase the Charge | 14.4V/28.8V/57.6V, the battery voltage is below 12V/24V/48V, start extra charge for 2 hours |
| Batterry overpressure protection | 15V/30V/60V |
| Input Reverse Connection Protection | Yes |
| Load Over Current Protection | Yes, every two seconds to restart |
| Charging Mode | PWM |
| Temperature Compensation | -24mV-48mV-96-mV relative to 12V/24V/48V System |
| Operating Temperation | -20 - +55 |
| Terminal Scale | 28-10AWG |
| Waterproof level | IP 32 |
| Product Size | 195mm*107mm*59mm |
| Weight | 850g |
