PHOCOS CIS 20A SOLAR CHARGE CONTROLLER
Distributor
Waterproof PV industrial Solar Charge Controller, 12/24V, IP68, timer
The Phocos CIS is a high-quality, 4-stage PWM-charging mode is combined with features such as: low-voltage disconnect, flexible load timer functions, and a multi-LED system status display. The Phocos CIS charge controller features a two loads timer (2L-series) to independently control dual loads. The CIS has no moving parts, switches or buttons. Settings such as battery type, deep discharge thresholds, timers, etc. are made quickly and easily via infrared remote control accessory. All devices are connected to the controller by supplied lead wires rather than wire terminals. This feature eliminates the risk of damage from external elements like corrosion, dust, water, bugs, chemicals, physical shock, where components make electrical contact to the controller. The extremely compact aluminum housing even allows for mounting CIS inside street light poles.
Key advantages
Robust aluminum housing
Epoxy encapsulated PCB to prevent corrosion
Waterproof (IP68) 1.5m for 72h
Compact size
Intelligent timer functions
Widely programmable (requires CIS-CU or MXI-IR)
External temperature sensor
4-Stage battery charging (main, float, boost, equalization)
Two independent outputs for dual loads (only 2L-series)
Automatic system voltage recognition (12/24V)
Max. panel voltage: 42/52V (Voc) in 12/24V systems
Max. panel current: 5-20A (Isc) depends on model
Grounding: possible on positive line (see N-Series for negative grounding on minus line)
Operating temperature: −40 to +60 °C
