Juniper Networks EX2200-48P-4G Ethernet Switch

Distributor

Get Quote

The EX2200 also supports Juniper Networks Virtual Chassis technology, allowing up to four interconnected switches to be managed as a single logical device, delivering a scalable, pay-as-you-grow solution for expanding networks.

Featuring complete Layer 2 and basic Layer 3 switching capabilities, the Juniper Networks® EX2200 line of fixed configuration Ethernet switches with Virtual Chassis technology satisfies the branch and low-density wiring closet connectivity requirements of today’s high-performance businesses. Four platform configurations are available offering 24 and 48 10/100/1000BASE-T ports with or without Power over Ethernet (PoE). The PoE- enabled EX2200 models include a maximum system budget of 405 W to deliver up to 15.4 watts of standards-based 802.3af Class 3 PoE or 30 watts of standards-based 802.3at PoE+ for supporting networked devices such as telephones, video cameras, multiple radio IEEE 802.11n wireless LAN (WLAN) access points and video phones in converged networks.

Product Specificaion
Product Reviews

Type:	Ethernet switch
Brand:	Juniper
DRAM:	512 MB
Switching Engine Model:	Store and forward
CPU:	800 MHz ARM CPU
Flash:	1Gb
GbE port density per system:	52 (48 host ports+ four-port GbE uplinks)
Packet Switching Capacities:	104 Gbps
Layer 2 Throughput (Mpps):	77.4 Mpps (wire speed)
Operating Temperature:	32° to 113° F (0º to 45º C)
Storage Temperature:	-40º to 158º F (-40º to 70º C)
Relative Humidity (Operating):	10% to 85% (noncondensing)
Relative Humidity (Non-Operating):	0% to 95% (no0% to 95% (noncondensing)ncondensing)
Altitude (Operating):	Up to 10,000 ft (3,048 m)
Altitude (Non-Operating) :	Up to 16,000 ft (4,877 m)
Cooling:	Airflow: 16.4 cfm
