Transmission line is an important part of power system. The cost and life of transmission line primarily depend on the material used for making conductor for transmission line. The most important and much suitable material for conductor of transmission line is copper as it having high conductivity and high tensile strength. More ever it is having good ductility. The only limitation is its cost. The most extensively used material in transmission line is Aluminum.
Aluminum is having sufficient conductivity. More ever it is light in weight. Which results in low conductor weight and less sag. The only limitation is its low tensile strength. To overcome this limitation steel core is used for increasing the tensile strength of aluminum conductor such as in ACSR (Aluminum conductor steel reinforced) conductor.
Properties of Aluminum
-
Resistivity: 2.65 µ -cm.
-
Temperature coefficient of resistance at 20oC: 0.00429 /oC.
-
Melting point: 660oC.
-
Specific gravity: 2.70 gm /cm3.
Use of Aluminum
The most extensively used material in transmission line is Aluminum. Aluminum is having sufficient conductivity. More ever it is light in weight. The only limitation is its low tensile strength. To overcome this limitation steel core is used for increasing the tensile strength of aluminum conductor such as in ACSR (Aluminum conductor steel reinforced) conductor. ACSR conductor is very much popular for high voltage overhead transmission lines.
