POWERWALL SOLAR HOME SYSTEM INTEGRATED 48V/100A LiFePo4 Battery
Distributor
POWERWALL/ SHS 4800 ALL -IN-ONE SOLAR HOME SYSTEM INTEGRATED 48V/100A LiFePo4 Battery
DESCRIPTION:
ALL- IN- ONE DESIGN
COMPACT AND PORTABLE
SPECIAL FEATURES
COMPACT DESIGN
• 3 Functions (PV & battery inverter + lithium-ion battery)
• Simple installation
• Remote maintenance
PROACTIVE A/S
• Prior malfunction sensing
• Web & Mobile monitoring for remote maintenance
• Local service network
SAFETY
• Battery cell approved for EV use
• VDE, TÜV tested lithium-ion battery and inverter
Battery rated voltage 48Vdc
Charge Current 30A (C0-C6 Can be set)
Battery Capacity 100AH
Input Voltage Range 170-275Vac
frequency 45-65Hz
Output voltage range 220Vac?±5%( Inverter mode)
frequency 50/60Hz±1%( Inverter mode)
Output wave Pure Sine Wave
Change time ?5ms(Typical load)
frequency ?90%?85% Resistive load?
overcharge Protection function : 110-120%/30S??160%/300ms?
Battery over-voltage and low-voltage protection,
Overload protection,
short circuit protection,
over-temperature protection
Solar MPPT Controller
Battery voltage 48Vdc
PV max Voltage ≤100 Vdc
Charge Voltage range 40-100 Vdc
Rated Charge Current – 60A Max
Max DC Power input 2880W
Overcharge Voltage : 56.8 Vdc
Overcharge recovery voltage : 56 Vdc
Floating charge voltage : 54.4 Vdc
Operating ambient temperature 0-40?
Storage ambient temperature -15 – +50?
Operating / storage environment : 0-90% No Condensation
